Table of Contents
ii
PS280 & PS283 User Manual
List of Figures
Figure 1: Line Voltage Selectors, Power Input,
and Fuse Locations 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 2: PS280 or PS283 Front Panel 4. . . . . . . . . . . . . . . . . . .
Figure 3: Constant Voltage/Constant Current Crossover 10. . . . . .
Figure 4: Independent Floating Application 12. . . . . . . . . . . . . . .
Figure 5: Independent Common Ground-Referenced
Application 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 6: Independent Ground-Referenced Split Application 15. .
Figure 7: Three Ground-Referenced Negative Power Supplies 16
Figure 8: Three Ground-Referenced Positive Power Supplies 17.
Figure 9: Independent Positive Stacked Application 18. . . . . . . . .
Figure 10: Independent Negative Stacked Application 19. . . . . . .
Figure 11: Series Tracking Inside the PS280 or PS283 20. . . . . . .
Figure 12: Series Tracking Application 21. . . . . . . . . . . . . . . . . . .
Figure 13: Parallel Tracking Inside the PS280 or PS283 23. . . . .
Figure 14: Parallel Tracking Application 24. . . . . . . . . . . . . . . . .
