TEL AFA 1000 - Dimensions

16
8.0 Dimensions
3.19″
(81mm)
5.2 ″
(132mm)
Alarm Panel
Dimensions
Panel Cutout
Dimensions
3.00″ x 2.00″
4.37 ″
(111mm)
R1
15V
T
EL
s
1
IDC
2
3
232
1.14
″
(29mm)
1.14
″
(29mm)
2.91
″
(74mm)
1.89 ″
(48mm)
0.75 ″
(19mm)
0.38 ″
(9.75mm)
Front
View
Rear
View
Side
View
1.59
″
(40.5mm)
1.59
″
(40.5mm)
2 x Fixing Holes
for 2 x No. 6
Self tapping screws provided
3.00″
(76.2mm)
2.00
″
(50.8mm)
4.37
″
(111mm)
