I.
Open
cover and
remove
power
cord,
mierophone,
empty
reel,
and
reel
oftape
from storage space
at
rear
of unit.
Remove
cover by sliding hinges
apart.
Place
unit so
that controls are accessible
and at a
convenient
height.
PREPARING
FOR OPERATION
FUNCTION
OF
CONTROLS
OPERATING
INSTRUCTIONS
Plug
power
cord
into
any AC outlet having
proper
frequency
and
power
requirements.
Recorder
is
now ready
for use.
Before
oper-
ating, the operator should
familiarize himseU
with the iunction
of the
controls.
3.
+.
2.
Function
Control
Idle is
neutral, or
stationary, tape
position.
Turn knob
to the
Ieft for Play. To
record, depress
Record
button
andhold while turning
function selector
knob
to the
right.
IMPORTANT:
When recorder
is not
in
use,
funetion
selector knob must be
in Idle
po-
sition.
Wind-Rewind
Control
Turn
control to the
right
for fast
wind; to the
left for fast rewind.
Before operating Wind-Rewind
knob,
function
selector knob must
be
placed
in IdIe
positlon.
Speed Change Control
For 7
l/
2 ips,
put
speed change
control
in down
positionl
for 3
3/
4 ips, in
up
position.
Do not
change
speedsunlessfunction selectorknobis
inldle
position.
Threading Tape
l.
Place
a
reel
of tape on the
left
(supply)
spindle
and anempty
reel
onthe
right
(take-up)
spindle,
making
sure the
reel
slots engage the spindle
pins.
2.
Unwindapproximately12 inches of tape from
left
(supply)
reel. HoId
a
section
of tape taut and
insert
intape slot, making sure duLl
coated
side
of tape
faces
rear
of
recorder.
3.
Insert
free end of
tape
into
one of three
radial
slots in hub of
empty
reel.
Turn
reel several
turns
counterclockwise
until
tape
is
secured to
reel
and
all
slack is taken up
between
reels.
To
Record
Plug
line
cord
into
a convenient wall receptacle
and insert
microphone
into
input
jack
on top of
re-
corder. Turn
On-Off-Volume
control clockwise until
a
click
is
heard
and allow suJficient
time for unit to
warm up.
Thread tape as described
under
"Threading
Tape". Turn
function selectorknob
to Record. Adjust
Volume
controluntil
recording
level indicator
flashes
on high
peaks
only. To
reeord
from radio,
phono-
graph,
or television, follow this
6ame
procedure,
keeping recorder
volume
at
a normal level, To
stop
tape,
turn function selector
knob to the Idle
position.
To
Wind
or Rewind
Tape
l.
Turn function selector
knob
to
ldle.
2.
To
wind
tape onto
reel,
turn Wind-Rewind con-
trol
to
right
and hold.
Release
the
control
when
the
desired section
of the
tape
is reached.
Page
2
3. To
rewind
tape,
turn
Wind-Rewind
control to
the left. The
control
need notbe held
as
it locks
into
position.
To stop rewind, return
the Wind-
Rewind knob
to
its
center
position.
To
Play
a
Recorded Tape
l. Follow
instructions
under
"Threading
Tape".
2.
Turn On-Off-Volume
control clockwise until a
click
is heard
and allow sulficient time lor unit
to warm up.
3.
Turn function
selector knob to
PIay.
4.
Adjust
Volume control for
desired listening
Ievel.
5. Turn function selector knob
to ldle to stop tape.
CAUTI0N:
Do
not
set
function
selector knob
to
Recordwhen
Play
is desired,
aspreviously
recorded
portion
of tape will be automati-
cally erased.
Erasing
Recorded
Material
Any
recording
on tape
is
automatically
erased
before
a new recording is
put
on
tape
when
it is in
Record. Toerase a recording
without
putting
anything
on tape,
follow normal recording
procedure,
but
leave
Volume control at
its
extreme counterclockwise
po
-
sition.
To
Edit and
Splice
Tape
NOTE:
Since
one track
cannot
be edited
and
spliced
without
affecting
the
other
track,
recordings
to
be edited
should
be
limited
