4.4 Model 913 and 923
High Capacity Power
Packs
The most popular power pack contains both a switching regu-
lator and a current-limited battery charging output. The
switching regulator provides a protected output of 12 VDC at 5
amperes. The charger’s output is regulated at 400 mA, suitable
for nickel-cadmium batteries.
The Model 913 is for 120 volts and Model 923 is for 230 volts.
Figure 4-3 Model 913 High Capacity Power Pack
