1 Introduction
TFB-180SA and TFB-180BSA are devices with a base for an addressable detector integrated
with an addressable horn or a base for an addressable detector integrated with an addressable
strobe horn.
There are two models:
• TFB-180SA – base for an addressable detector integrated with an addressable horn
• TFB-180BSA – base for addressable detector integrated with an addressable strobe horn
The bases comply with the Telefire addressable detector series (TFO-480A ,TFH-280A ,
and TPH-482A).
Pressing the Horn Silence button in the fire detection panel stops the operation of the horn and
strobe light.
2 Compatibility
2.1 Fire detection panels
The addressable strobe horn and horn comply with the following panels:
• ADR-7000 ,SAVER-7000 ו , - GUARD-7
• ADR-3000 ו- ADR-SAVER
2.2 Detectors
The addressable strobe horn and horn serve as a basis for the following detectors:
• TFO-480A
• TFH-280A
• TPH-482A
3 Installation
The quantities and location of detectors and alarm devices will be planned according to the
latest Israeli standard IS 1220, part 3, and upon the requirements of the planning consultant.
3.1 Planning of the installation
3.1.1 Capacity Planning
Make sure the fire detection panel has free addresses, as necessary.
3.1.2 Wiring planning – communication line to addressable devices
Use a 2-strand wire of 12-20AWG (section area – quadrat – of 0.5-3.3mm
2
). The
following table presents the maximum line lengths by the section area of each cable
strand. It is recommended to use a twisted pair when the detection loop connects
between different buildings.
