Telefunken D43F278A3C User Manual

English - 56 -
Connectivity
Wired Connectivity
To Connect to a Wired Network
• You must have a modem/router connected to an
active broadband connection.
• Ensure that Nero Media Home software is installed
to your PC (for Audio Video Sharing function). See
“Nero Media Home Installation” section.
• Connect your PC to your modem/router. This can
be a wired or wireless connection.
• Connect your TV to your modem/router via an
ethernet cable. There is a LAN port at the rear
(back) of your TV.
Broadband ISP connection
LAN (ethernet) cable
LAN input on the rear
side of the TV
• To access and play shared les, you must select the
Media Browser. Press the Menu button and select
Media Browser. Press OK to continue. Select the
desired le type and press OK. You must always
use the Media Browser screen to access and play
shared network les.
• PC/HDD/Media Player or any other devices that are
compatible should be used with a wired connection
for higher playback quality.
To configure wired settings please refer to
the Network/Internet Settings section in the
System>Options Menu.
• You might be able to connect your TV to your LAN
depending on your network’s conguration. In such
a case, use an ethernet cable to connect your TV
directly to the network wall outlet.
LAN input on the rear
side of the TV
network
wall socket
ConguringWiredDeviceSettings
Network Type
The Network Type can be selected as Wired Device,
Wireless Device or Disabled, in accordance with the
active connection to the TV set. Select this as Wired
Device if you are connecting via an ethernet.
Internet Speed Test
Highlight Internet Speed Test and press the OK but-
ton. TV will check the internet connection bandwidth
and display the result when complete.
Advanced Settings
Highlight Advanced Settings and press the OK
button. On the next screen you can change the IP
and DNS settings of the TV. Highlight the desired one
and press Left or Right button to change the setting
from Automatic to Manual. Now you can enter the
Manual IP and / or Manual DNS values. Select the
related item in the drop down menu and enter the
new values using the numeric buttons of the remote.
Press the OK button to save settings when complete.
Wireless Connectivity
To Connect to a Wireless Network
IMPORTANT: “Veezy 200” USB dongle is required to
use wireless network features.
The TV cannot connect to the networks with a hidden
SSID. To make your modem’s SSID visible, you should
change your SSID settings via the modem’s software.
To Connect to a wireless LAN, you should perform
the following steps:
1. Ensure that Nero Media Home software is
installed to your PC (for Audio Video Sharing
function).
2. Then connect the wireless adaptor to one of the
USB inputs of the TV.
3. To congure your wireless settings please refer
to the Network/Internet Settings section in the
System>Options Menu.

Telefunken D43F278A3C Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Display diagonal (metric)	109 cm
Motion interpolation technology	CMP (Clear Motion Picture)
Dynamic contrast ratio marketing name	Mega Contrast
3D	No
Annual energy consumption	78 kWh
RF connector type	F
RF ports quantity	1
HDMI ports quantity	3
DVI-D ports quantity	0
Common interface (CI)	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Tuner type	Analog & digital
Digital signal format system	DVB-C, DVB-CI+, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	16 W
Number of speakers	2
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	54 W
Number of OSD languages	4
On Screen Display (OSD) languages	DEU, ENG, FRE, ITA
Product color	Black
Panel mounting interface	200 x 200 mm
Package depth	178 mm
Package width	1195 mm
Package height	718 mm
Package weight	12000 g

Weight and Dimensions

Depth (with stand)	220 mm
Width (with stand)	974 mm
Height (with stand)	615 mm
Weight (with stand)	9500 g
Depth (without stand)	98 mm
Width (without stand)	965 mm
Height (without stand)	572 mm
Weight (without stand)	8650 g
