English - 8 -
Specification
TV Broadcasting
PAL BG/I/DK
SECAM BG/DK
Receiving Channels
VHF (BAND I/III) - UHF
(BAND U) - HYPERBAND
Digital Reception
TV(DVB-T-C-S)
(DVB-T2, DVB-S2
Number of Preset
Channels
11 000
Channel Indicator On Screen Display
RF Aerial Input 75 Ohm (unbalanced)
Operating Voltage 220-240V AC, 50Hz.
Audio German+Nicam Stereo
Audio Output Power
(WRMS.) (10% THD)
2 x 6
Power Consumption (W) 60
Networked Standby Mode
Power Consumption (W)
< 2
TV Dimensions DxLxH
(with stand) (mm)
197 x 734 x 480
TV Dimensions DxLxH
(without stand) (mm)
78 x 734 x 435
32”
Operation temperature
and operation humidity
0ºC up to 40ºC, 85%
humidity max
Wireless LAN Transmitter Specifications
Frequency Ranges Max Output Power
2400 - 2483,5 MHz (CH1-CH13) < 100 mW
5150 - 5250 MHz (CH36 - CH48) < 200 mW
5250 - 5350 MHz (CH52 - CH64) < 200 mW
5470 - 5725 MHz (CH100 -
CH140)
< 200 mW
Country Restrictions
This device is intended for home and office use in
all EU countries (and other countries following the
relevant EU directive). The 5.15 - 5.35 GHz band is
restricted to indoor operations only in the EU countries.
Country Restriction
Bulgaria
General authorization required for outdoor
use and public service
Italy
If used outside of its own premises, general
authorization is required. Public use is
subject to general authorisation by the
respective service provider
Greece
In-door use only for 5470 MHz to 5725
MHz band
Luxembourg
General authorization required for network
and service supply(not for spectrum)
Norway
Radio transmission is prohibited for the
geographical area within a radius of 20 km
from the centre of Ny-Ålesund
Russian
Federation
In-door use only
Israel
5 GHz band only for 5180 MHz-5320
MHz range
The requirements for any country may change at
any time. It’s recommended that user checks with
local authorities for the current status of their national
regulations for 5 GHz wireless LAN’s.
