Item No. Description Quantity Req. Designator Remarks
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C704
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C713
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C714
08-0D276X-PWY ASS'Y - POWER PARTS 1
10-0001H8-FBX DIODE 1H8 (FAST RECOVERY) 1 D810
10-00RU3C-F0X DIODE RU3C (FAST RECTIFIER) 1 D824
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D801
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D802
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D803
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER) 1 D804
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D832
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D807
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D805
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D833
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q806
13-TDA168-46P IC TDA16846 (SMPS) 1 IC801
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R829
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R828
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R804
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R827
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R826A
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R826
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% 1 R812
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% 1 R806
18-CB0752-JNX RES. C.F. 7.5K OHM 1/6W +/-5% 1 R810
18-CB0823-JNX RES. C.F. 82K OHM 1/6W +/-5% 1 R803
18-CD0101-JNX RES. C.F. 100 OHM 1/4W +/-5% 1 R808
18-CD0153-JNX RES. C.F. 15K OHM 1/4W +/-5% 1 R811
18-CD0470-JNX RES. C.F. 47 OHM 1/4W +/-5% 1 R808A
18-CE0102-JNX RES. C.F. 1k OHM 1/2W +/-5% 1 R808B
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5% 1 R831
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5% 1 R832
18-FE0120-JNX RES. M.0. 12 OHM 1/2W +/-5% 1 R825
18-FG0121-JHX RES. M.O. 120 OHM 2W +/-5% 1 R854A
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R824
18-FG0563-JHX RES. M.O. 56K OHM 2W +/-5% 1 R809
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W 1 R805
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W 1 R835
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W 1 R835A
20-TR502H-5CX TRIMMER B5K HORIZ TYPE 1 VR801
25-315130-M1X CAP. ELEC 330UF 400V +/-20% 1 C809
