Telefunken TK2129ST - Page 10

Item No. Description Quantity Req. Designator Remarks
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R504
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R507
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R512
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J503
46-10967W-01X PIN BASE *1 TJC1-1A 1 P501 FOR CRT GROUNDING
47-265540-0U7 SOCKET CRT GZS10-2-4 (C.B.) 1 S501
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C506
08-02109X-MPY ASS'Y - MPX PARTS 1
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q701
13-0TDA98-50P IC TDA9850 (MPX) 1 IC701
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R706
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R702
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R703
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R707
18-CB0511-JNX RES. C.F. 510 OHM 1/6W +/-5% 1 R704
18-CB0511-JNX RES. C.F. 510 OHM 1/6W +/-5% 1 R705
18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R701
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C703
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C706
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C717
27-MBC224-J0X CAP. M.P.E 0.22UF 63V +/-5% 1 C710
27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C709
27-PBC153-J0X CAP. P.E 0.015UF 63V +/-5% 1 C715
27-PBC473-J0X CAP. P.E 0.047 UF 63V +/-5% 1 C701
34-R330J2-0EX COIL PL - 33 UH +/-5% 1 L701
41-BF0180-3BB WIRE UL 1007 #24 180mm ORANGE 1 FOR L - L
41-BF0180-9BB WIRE UL1007 #24 180mm WHITE 1 FOR R - R2
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J704
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J701
45-COS500-KN0 CER. RESONATOR 514.5KHz 1 Z701
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C719
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C718
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C712
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C707
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C702
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C716
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C708
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C705
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C721
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C720
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C711
10
