Item No. Description Quantity Req. Designator Remarks
08-02109X-CR3 ASS'Y - CRT PARTS 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
11-0BF422-0BX TRANSISTOR BF422 (NPN) 1 Q501
11-0BF422-0BX TRANSISTOR BF422 (NPN) 1 Q503
11-0BF422-0BX TRANSISTOR BF422 (NPN) 1 Q505
11-A562TM-0BX TRANSISTOR 2SA562TM-0 1 Q507
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q502
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q504
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q506
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R515
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R514
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R501
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R505
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R510
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R503
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R508
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R513
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R502
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R506
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R509
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R511
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R522
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R519
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R520
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R521
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R516
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R517
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R518
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C504
26-AMK102-KRX CAP. CER 1000 pF 2KV +/-10% R 1 C505
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C509
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C508
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C501
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C502
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C503
34-R100K2-1BX COIL CHOKE 10 UH +/-10% 1 L502
35-139730-00X FERR. BEAD BF60 2 FOR C508 (L505 & L506)
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L504
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L501
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L503
9
