Telefunken TK2129ST - Page 24

Item No. Description Quantity Req. Designator Remarks
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J225
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J302
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J403
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J912
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J213
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 R417
41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J230
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J903
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J228
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J229
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J103
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J231
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J108
41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J404
45-FIL4M5-0Y1 CERAMIC FILTER SFSH4.5MDB 1 X208
45-OSC8M0-0Y0 CRYSTAL 8.0MHZ 1 X001
45-SAW185-9M0 SAW FILTER M1859M (45.75MHz) 1 Z101
45-TRA4M5-0Y0 CER TRAP TPS 4.5MHZ 1 X203
46-12866W-02X PIN BASE *2 S11-02Y 1 P601 FOR F.CAB (SPK)
46-20598W-04X PIN BASE *4 TJC1-4A 1 P401 FOR DY CONNECTOR
46-29355H-04X HS 4P24 450 2*SCN-4Y 1 FOR P402 TO CRT PARTS (P502)
46-29356H-05X HS 5P24 450 F/W 2* SCN-5Y 1 FOR P201 TO CRT PARTS (P503)
46-33079W-02X PIN BASE *2 TJC3-2A 1 P001 FOR AGING TEST
46-33079W-02X PIN BASE *2 TJC3-2A 1 P002 FOR AGING TEST
46-33079W-02X PIN BASE *2 TJC3-2A 1 P602 FOR F.CAB (SPK)
46-33079W-06X PIN BASE *6 TJC3-6A 1 P101A FOR W.BAL. ADJUST
46-33079W-06X PIN BASE *6 TJC3-6A 1 P904 FOR SIDE AV BD P1104B
47-RCA021-XX0 RCA JACK 6P RED/SW. WHT. YEL 1 P901
62-10654X-00F UNI-TIE (2.5mmX95mm) 8
62-227680-0UA BRACKET ABS-KINGFA 606 (UO) 1
62-291630-0HH MTG SPACER FBT&H.SINK 1 FOR FBT & H.SINK
63-B40150-AB2 S/T SCREW B 4 X 15 AB 1 FOR FBT & H.SINK
64-P30060-104 M/C SCREW 3 X 6 (ZINC) 1 FOR IC401
64-P30100-104 M/C SCREW P 3 X 10 2 FOR IC301 & Q402
64-P30100-104 M/C SCREW P 3 X 10 2 MTG IC603
65-Z30050-23M NUT M 3 2 FOR IC301 & Q402
65-Z30050-23M NUT M 3 2 FOR IC603
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T402
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR L411
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR L412
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T802
24
