Telefunken TK2129ST - Page 25

Item No. Description Quantity Req. Designator Remarks
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR C827
67-H10918-4M2 HEAT SINK 1 FOR IC401
67-H30752-1A0 HEAT SINK 1 FOR IC301
67-H30752-4A0 HEAT SINK (A=75MM) 1 FOR IC603
67-H30752-5A0 HEAT SINK 1 FOR Q402
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J051
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R105
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R106
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 J063 (-) TO R825
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D401
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D402
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D403
36-HDR001-AX1 TRANSFOR HOR. DRIVE (MAGNETIC CORE) 1 T401
67-H10918-4M2 HEAT SINK 1 FOR IC402
64-P30060-104 M/C SCREW 3 X 6 (ZINC) 1 FOR IC402
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C416
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C904
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C905
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C907
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C908
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C041
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C217
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C236
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C245
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C246
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C615
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C901
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C101
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C225
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C624
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C030
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C912
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C921
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C224
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C103
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C028
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C202
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C241
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C423
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C285
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C418
