The device described in this manual is the Telegrapher Gorilla mid-field monitor, designed for critical mixing and mastering applications. It is a high-quality analog loudspeaker, hand-made in Istanbul.

Function Description

The Telegrapher Gorilla serves as an analog mid-field monitor, providing accurate sound reproduction for professional audio environments. Its primary function is to allow users to realize their audio endeavors at the highest level, making it suitable for critical listening tasks in mixing and mastering.

Important Technical Specifications

Dimensions and Weight:

Dimensions (H x W x D): 318 x 450 x 275 mm
Weight: 27 Kg each

Amplifiers: The Gorilla features a tri-amplified design with dedicated power for each driver:

Tweeter: 100 Wrms
Mid: 350 Wrms
Woofer: 350 Wrms

Key amplifier features include:

Load-Independent Frequency Response
Frequency-Independent THD (Total Harmonic Distortion)
Over Current / Thermal Protection
Auto Standby

Drivers:

Tweeter: 2.5 cm coated textile diaphragm with Patented Symmetrical Drive (SD-2)
Mid: 12 cm paper cone with Patented Symmetrical Drive (SD-3)
Woofer: 22 cm aluminum cone with Patented Symmetrical Drive

Operating Voltage:

Min Voltage: 100-120 Volts AC ±10%
Max Voltage: 200-240 Volts AC ±10%
Voltage Frequency: 47 - 63 Hz
Connector: 3-pin IEC 250 Volts AC, 10A male
Input Power: 800W max

Inputs: The Gorilla offers both balanced and unbalanced analog input options:

XLR (Balanced Analog Input):
- Pin 1: Shield
- Pin 2: Positive (+ or hot)
- Pin 3: Negative (- or cold)
- Input impedance: Differential: 500 KOhm, Common Mode: 300 KOhm
- Nominal level: TBD
RCA (Unbalanced Analog Input):
- Sleeve: Shield (Ground)
- Tip: Positive (+ or hot)
- Input impedance: 300 kOhm
- Nominal level: TBD

Usage Features

Input Selection: Users can select between XLR (balanced) and RCA (unbalanced) inputs using the input select button located on the back panel.

Standby Function: The device includes a standby feature that can be toggled on or off via a button on the back panel. If the standby function is enabled and no signal is detected for 120 minutes, the Gorilla will automatically turn off to conserve power.

Driver Placement: For optimal listening, the tweeters of the Gorilla loudspeakers should be positioned inside the user's listening point.

Safety Precautions:

Operates at mains voltage and carries hazardous voltages.
Avoid exposure to rain, water, or moisture to prevent fire or electric shock.
Do not place near heat sources like amplifiers.
Ensure electrical power is off before connecting or disconnecting cables.
Avoid direct sunlight.
The product should not be disposed of with household waste due to potentially hazardous substances. Contact local authorities for recycling information.

Protection Circuits: The Gorilla incorporates four protection circuits:

Thermal Protection: If the maximum temperature is reached, amplifiers switch off, and a red protection LED on the front illuminates.
Electrical Failure/High Frequency Signal Protection: In case of a critical electrical failure or high-frequency signal (e.g., microphone feedback), amplifiers shut down immediately, and the red protection LED activates.
- Recovery: Unplug the power cord, wait approximately 3 minutes for the back panel to cool and the red light to turn off, then plug the power cord back in and power on the Gorilla.
Clipping Warning: A blinking red LED on the front indicates that the amplifiers are clipping. Users should lower the input signal until the blinking stops.
- Clipping Protection: Excessive clipping will cause the amplifiers to shut down to protect the gear.
- Recovery: Similar to other protection events, unplug the power cord, wait about 3 minutes for the red light to turn off, then plug in and power on.

Maintenance Features

Service and Warranty:

Modifications by unauthorized personnel will void the warranty.
The device comes with a two-year limited warranty from the original purchase date, covering defects due to faulty workmanship or materials under normal use.
The warranty does not cover cosmetic deterioration, damage from accidents, misuse, neglect, or transporting.
To claim warranty, notify Telegrapher Loudspeakers during the warranty period with reasonable evidence of the claim date and the original purchase receipt. Replacement products do not renew the 2-year warranty coverage.

Troubleshooting:

No Power: Check the power outlet. If the internal fuse is blown (not user replaceable), contact Telegrapher Loudspeakers for service.
No Sound:
- A protection circuit might be triggered (e.g., module overheated). Try cycling the mains power.
- Check the source signal.
- Check the cables.

General Usage Advice:

Do not leave loudspeakers on at night unmonitored.
Turn off after use.

Support: Telegrapher Loudspeakers offers support through their website, where users can find manuals, datasheets, and contact them via a form for any questions.
