2
MAINS PRESSURE DOMESTIC HOT WATER APPLIANCE
STORAGE
CAPACITY
IN LITRES
90
125
150
170
200
250
300
Tempest & Tornado Stainless
Mains pressure domestic hot water cylinder
WARNING TO USER:
This appliance must be serviced annually by a competent person.
Failure to comply with the above will invalidate the manufacturer’s
warranty.
Do not remove or adjust any component part of this unvented
water heater: Contact the installer.
If this unvented water heater develops a fault, such as a flow of hot
water from the discharge pipe, switch the heater off and contact
the installer.
WARNING TO INSTALLER:
This installation is subject to building regulation approval, notify
Local Authority of intention to install.
Use only manufacturer’s recommended replacement parts.
Installed by:
Name: ..................................................................................
Address: ..............................................................................
.............................................................................................
Tel. No.: ...............................................................................
Completion Date: .................................................................
Water Supply Pressure
Max
12 Bar
Min
1.5Bar
Electric Immersion Heaters
14“/3kW • 230V AC
Operating Pressure
3 BAR
Expansion Vessel charge Pressure
3 BAR
Expansion relief valve setting
5 BAR
Pressure & Temperature relief valve setting
7 BAR • 90ºC
Maximum Primary working Pressure
3 BAR
APPLIANCE SERIAL NO:
Weight and litre capacity
Indirect Direct
Technical help line: 01952 257961
Telford Copper Cylinders Limited Unit 22 Furrows Business Park Telford TF1 2FE
WEIGHT
WHEN FULL
IN KGS
125
165
195
220
250
310
360
Ltrs Kgs
