Telma TRCM2 TL133013 - Kits

TL133013 TRCM2 iRCS Dyno User Guide
Page 2 of 6________________________________________________________________________21mar19jh
1.1 TRCM2 PWM control for Dynamometer or other industrial applications
The Telma Retarder Control Module (TRCM2) is the control module used for Telma systems. It can be used in a
dynamometer or other industrial application along with our iRCS power module using a simple variable voltage input
to proportionally control power to the Telma using pulse width modulation.
1.2 Kits
iRCS CONTROL KIT INDUSTRIAL 12V TIK14300
DESCRIPTION TELMA P/N QTY
iRCS 12V JE1002122 1
TRCM2 TIG31069 1
TRCM DTM PLUG
(
GRY
)
TIG31070 1
TRCM DTM PLUG
(
BLK
)
TIG31071 1
TRCM DTM 12WAY WEDGLOCK TIG31072 2
TRCM DTM TERMINALS TIG31067 10
iRCS CONTROL KIT INDUSTRIAL 24V TIK24300
DESCRIPTION TELMA P/N QTY
iRCS 24V JE1002344 1
TRCM2 TIG31069 1
TRCM DTM PLUG
(
GRY
)
TIG31070 1
TRCM DTM PLUG
(
BLK
)
TIG31071 1
TRCM DTM 12WAY WEDGLOCK TIG31072 2
TRCM DTM TERMINALS TIG31067 10
