-18-
TECHNOLOGY 150-170-200-186CE/GE
FIG. 2A
FIG. 2B
POSITIVE DINSE
D9
YELLOW LED
ALARM
BOTTOM
COVER SCREWS
NEGATIVE DINSE
SW1
SWITCH
SELECTION
TIG/LIFT-HARD-SOFT
BOTTOM
COVER SCREWS
BOTTOM
COVER SCREWS
BOTTOM
COVER SCREWS
MAINS CABLE
GENERAL SWITCH
FAN
CURRENT
POTENTIOMETER
BOTTOM
COVER SCREWS
