Wintering: For storage period exceeding 1 month, switch the battery into winte-
ring mode. To activate it, follow these steps:
1. Check that your battery is showing a charge level of less than 50% by pressing
the ON/OFF button on the battery for 2 seconds (try to ensure that there are two
green LEDs at maximum on the battery).
2. Connect the charger to connector at the back of the battery, then plug it to the
main power.
3. Keep pressing the ON/OFF button on the battery for 5 seconds. When the
wintering mode is activated, the rst LED ashes alternately red and green. The
battery LEDs will light up gradually as the battery recharges.
4. When the charging level reaches 50%, the wintering mode
is activated and the battery switches to standby mode (all
lights switch off).
5. Disconnect the charger when the battery is in standby
mode by rst removing the wall plug.
6. The wintering mode is automatically deactivated when the
battery is reconnected or plugged onto the motor.
Charger 220V : Charge the TEMO
.
1000 to 100% before the rst use. Remove the cap
from the charging connector and insert the charger cable, then plug the charger into a
220V socket. The charger indicator turns red during the charging process and then green
when fully charged. Put the plug back on the connector before use. Charge in a temperate
area. Check the charge level every 3 months.
Motor bracket: To be xed to the transom of your boat using the pressure
screws. Then slide your motor into the bracket to secure it and lower the main
handle so that the motor is locked in place. Before you reverse, make sure the
stand is pushed to the rear .
Back connector
(for charging)
Front connector
Slide the motor into
the motor bracket
Stand
Pressure screw
360° rotating
bracket
Locking lever
2. CHARGING AND INSTALLATION
