INSTALLATION INSTRUCTIONS R−410A Ductless Split System: DLF4(A/H), DLC4(A/H)
4 421 01 9220 00
DIMENSIONS − OUTDOOR
UNIT SIZE − 09
21.3
(541)
(Net Operating Weight: 96 lbs.- 44 kg.)
A12380
in. (mm)
10
(254.0)
30
(762.0))
23.2
(589.3)
11.3
(287.0)
33.4
(848.4)
12.6
(320.0)
21.3
(541.0)
UNIT SIZE − 12
(Net Operating Weight: 107 lbs.- 49 kg.)
A12381
