FMA4X, FMA4P: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
7
- NOTES: Shaded boxes represent airflow outside the required 300-450 CFM/ton.
1. Airflow data includes electric heat and filter.
2. Airflow data is with no return grill. When using a return grill on 18 & 24 sizes, decrease numbers above by approx. 10 CFM. For 30 & 36 sizes, decrease numbers above by approx. 50 CFM
- NOTES: Shaded boxes represent airflow outside the required 300-450 CFM/ton.
1. Airflow based upon dry coil at 230V with no electric heat and factory-approved filter. For FMA4X airflow at 208V is approximately the same as 230V because the multi-tap ECM motor is a constant
torque motor. The torque doesn’t drop off at the speeds in which the motor operates.
2. Airflow is equivalent for front or bottom return configurations.
Table 4 – PSC -Airflow Performance (Standard CFM)
MODELS BLOWER SPEEDS
EXTERNAL STATIC PRESSURE (IN WC.)
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
FMA4P1800AL
High
813 775 731 692 653 609 560 501 424
Med
695 656 620 581 540 498 440 380 -
Low 603 562 525 485
443 393 - - -
FMA4P2400AL
High
947 895 847 799 753 704 655 592 530
Med 845 801 759 716 675 626
573 510 -
Low 676 640
602 563 523 499 - - -
FMA4P3000AL
High
1367 1312 1252 1192 1131 1063 990 908 821
Med
1211 1165 1114 1065 1016 960 899 833 748
Low 992 952 912 873 828 782
728 656 627
FMA4P3600AL
High
1397 1345 1290 1263 1196 1116 1051 980 907
Med 1298 1252 1198 1147 1094 1037 976 910
842
Low 1149 1105 1056 1008 960 909
856 791 726
Table 5 – ECM - Airflow Performance (Standard CFM)
MODEL SIZE BLOWER SPEEDS
EXTERNAL STATIC PRESSURE (IN WC.)
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
FMA4X1800AL
Tap (5)
913 881 848 818 792 763 731 691 650
Tap (4)
825 787 753 717 682 650 617 580 540
Tap (3)
737 700 663 630 589 550 511 474 436
Tap (2) - Factory 675 632 596 555 521 480
440 399 366
Tap (1) 590 548 499 455
430 368 338 309 263
FMA4X2400AL
Tap (5)
913 881 848 818 792 763 731 691 650
Tap (4) - Factory 825 787 753 717 682 650 617
580 540
Tap (3) 737 700 663 630
589 550 511 474 436
Tap (2) 675 632
596 555 521 480 440 399 366
Tap (1)
590 548 499 455 430 368 338 309 263
FMA4X3000AL
Tap (5)
1362 1325 1266 1238 1197 1159 1119 1080 1040
Tap (4)
1282 1242 1176 1151 1111 1071 1028 975 936
Tap (3)
1267 1225 1143 1120 1078 1036 993 942 897
Tap (2) - Factory
1157 1111 1052 1016 971 929 884 842 802
Tap (1) 1077 1028 965 932 886 850 804 768
732
FMA4X3600AL
Tap (5)
1362 1325 1266 1238 1197 1159 1119 1080 1040
Tap (4) - Factory 1282 1242 1176 1151 1111 1071 1028 975 936
Tap (3) 1267 1225 1143 1120 1078 1036 993 942
897
Tap (2) 1157 1111 1052 1016 971 929
884 842 802
Tap (1) 1077 1028 965 932
886 850 804 768 732
