Tenda 4G185 User Manual

English
06
Charge your Hotspot
With no battery installed, 4G185 can still be powered on as long as it is connected to a
power supply device (such as a power adapter, laptop or portable charger) with the
USB cable.
If you need to use 4G185 with a power supply device always connected, you can
remove the battery for protection to extend its lifespan.
After the battery is fully charged, you can remove the charger to avoid shorter battery
lifespan caused by overcharge.
Tips
•
•
•
Method 1: Connect to a power socket (5V 1A).
Method 2: Connect to a computer by using the USB cable.
5V 1A

Tenda 4G185 Specifications

General

USB powered	Yes
Output voltage	51 V
Power source type	Battery
Cables included	USB
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE Granted ROHS Granted
3G/4G USB modem compatibility	No
4G standard	LTE-FDD
2G standards	GSM
3G standards	UMTS
USB 2.0 ports quantity	1
Type	Wireless
Modem speed	150000 Kbit/s
Product type	Portable router
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	10 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
Security algorithms	WEP, WPA, WPA-PSK, WPA2-PSK
Antennas quantity	2

Weight and Dimensions

Depth	980 mm
Width	595 mm
Height	138 mm
Weight	85 g
Dimensions (WxDxH)	59.5 x 13.5 x 98 mm
