LAN
LAN
PoE
WAN
OUT
POWERPOWER PoE PORTS LAN AUDIO HDMI
13
24
VGA USB1 USB2
IN
152
LAN
Câmera PoECâmera PoE Câmera PoE Câmera PoE
Monitor
Cabo HDMI
ou VGA
PoE NVR
Cabo Ethernet
Computador
Roteador
Internet
A K4P-4CR da NVR será utilizada como exemplo.
3
Conectar o dispositivo
