4
1
Install the HDD
If the kit does not include any HDD, please prepare it by yourself. You are recommended to
use the HDD dedicated for surveillance.
Unfasten the screws on the bottom, then remove the cover of the NVR. Reserve the
screws for later use.
Take out 2 screws from the NVR installation package, and screw them into the two screw
holes closest to the SATA connector. Reserve about 2 mm between the screw head and
the HDD for subsequent installation.
Tips
Remove the cover
SATA connector
Flip
When installing or replacing the HDD, please cut off the power supply of the NVR first;
otherwise, the HDD may not be detected or even be damaged.
POWER
OUT
IN
English
POWER
To Next Page
