LAN
PoE
WAN
OUT
POWERPOWER PoE PORTS LAN AUDIO HDMI
13
24
VGA USB1 USB2
IN
176
LAN
LAN
Камера PoE Камера PoE Камера PoE Камера PoE
Монитор
Кабель HDMI или
кабель VGA
Видеорегистратор PoE
Сетевой кабель (Ethernet)
Компьютер
Маршрутизатор
Интернет
Здесь в качестве примера используется набор K4P-4CR.
3
Подключение устройства
