Max. allowable input
IOV rms
Voltage:
Input impedance:
Approx.10kn
Output impedance:
600n ±10%
Output attenuator:
OdB, -10dB, -20dB, -30dB, -40dB and -50dB in 6
steps (accuracy: ±1dB
at 600n load) .
[Stability against power source voltage variation (with
respect
to variation of 110V ±10%)]
Frequency
drift:
Within ±0.5%
Output voltage variation:
Within ±0.5dB
Operating
temperature:
0-50°C (relative humidity: Less than 90%)
Power requirement:
AC 110V or 220V, 50-60Hz
Power consumption:
5 watts
-2-
External view:
See Fig. 2 on page 9
Dimensions:
Casing; 142(W) x 233(D) x 197(H) mm
Overall (including knobs), 144(W)
x 260(D) x 206(H)
mm
Weight:
3.5 kg
Accessories:
Power cord 1
Test Lead:GTL-103 1
Instruction
manuaL J
