Page <7>
V1.026/04/18
5 - Structure Description
5.1 - Back View
1 - Infrared Camera Lens
2 - Trigger
3 - LCD Display
4 - Buttons
HOME Button
Shutter Button
Power Button
Save Image Button
Laser Button
5 - Battery
USB Data transform between Camera and PC
Video out Composite (PAL and NTSC)
Power System
Battery Lithium Polymer Battery, 4.5 hours operating time
Input voltage DC 9V to 12V
Charging system In Camera (AC Adapter)
Power management Automatic shutdown and sleep mode (User Selectable)
Environmental Data
Operating temperature range -20°C to +50°C (-4°F to +122°F)
Storage temperature range -40°C to +70°C (-40°F to +158°F)
Humidity (operating and storage) 10% to 90%
Encapsulation IP65
Drop test 2m
Bump 25g (IEC60068-2-29)
Vibration 2g (IEC60068-2-6)
Physical Data
Camera weight, incl. Battery 920g
Camera size (L x W x H) 243 × 103 ×160
