STANDARD PARTS
Tennant T500 (01- 2017)
41
HEAD LIFT GROUP, ORBITAL
Ref. Part No. Serial Number Description Qty.
1 1221206 (10000000- 20000000 ) Actuator, 24vdc, 07.0strk, 0600lb 1
2 29558 (10000000- 20000000 ) Pin, Clevis, 0.37d X 1.50l 1
3 140626 (10000000- 20000000 ) Pin, Cotter, Hair, 0.25d .125 Wir 1
4 1226754 (10000000- 20000000 ) Pin, Clevis, .50d X 7.00l 1
5 1226759 (10000000- 20000000 ) Spacer, .500 Id X .875 Od 1
6 1224233 (10000000- 20000000 ) Pin, Guide, Spring, Head 2
7 1013936 (10000000- 20000000 ) W asher, Flat, 0.51b 0.94d .10, Nyl 1
8 1226640 (10000000- 20000000 ) Spring, Wave, .512 Id X .709 Od X .375 1
9 32486 (10000000- 20000000 ) W asher, Flat, 0.53b 1.06d .10, Stl, Pl 1
10 1225960 (10000000- 20000000 ) W asher, Thrust, 0.89b 1.50d 0.13w, Bnz 2
11 1227036 (10000000- 20000000 ) Spring, Cmpr, 1.10od .085wir 03.0l 2
12 1059990 (10000000- 20000000 ) Sleeve, Flng, 0.32b 1.00/0.50d 0.6l, Ss 3
13 608562 (10000000- 20000000 ) W asher, Flat, 0.51b 0.94d .06, Nyl 6
14 630188 (10000000- 20000000 ) Bearing, Journal, .50id X .25l 3
15 01685 (10000000- 20000000 ) W asher, Flat, 0.38b 0.88d .08, Ss 3
16 74440 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 40, Nl, Ss 2
17 1016399 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 30, Nl, Ss 1
18 1212543 (10000000- 20000000 ) Isolator, Neoprene, 1.25” X 1.25”, M8 2
19 1020341 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 20, Ss, Sems 2
20 1224295 (10000000- 20000000 ) Brkt Wldt, Lift 1
21 01685 (10000000- 20000000 ) W asher, Flat, 0.38b 0.88d .08, Ss 2
22 08713 (10000000- 20000000 ) Nut, Hex, Lock, M8 X 1.25, Nl, Ss 2
23 33933 (10000000- 20000000 ) Screw, Pan, Phl, M3 X 0.50 X 25, Ss 6
24 1215716 (10000000- 20000000 ) Switch, 0.1a, Spdt[Micro, Gold Contacts] 3
25 1013705 (10000000- 20000000 ) Plate, Thread, Switch, M3 Nut, 96hr Pl 3
26 49263 (10000000- 20000000 ) Tie, Cable, Nyl, 11.4l .19w 3.0 Max D 5
To Next Page
