tennat t500 - Default Chapter; Table of Contents

TABLE OF CONTENTS
Tennant T500 (01- 2017)
5
STANDARD PARTS
GENERAL RECOMMENDED MAINTENANCE
ITEMS 7...................................
REPLACEMENT BRUSHES AND PAD
DRIVER DISK 10............................
REPLACEMENT BRUSHES CYLINDRICAL 12....
REPLACEMENT PADS ORBITAL 13.............
SCRUB HEAD GROUP, DISK 650MM / 26IN 14...
SCRUB HEAD GROUP, DISK 700MM / 28IN 16...
SCRUB HEAD GROUP, DISK 800MM / 32IN 18...
SCRUB HEAD GROUP, CYLINDRICAL
700MM / 28IN 20............................
SCRUB HEAD GROUP, CYLINDRICAL
700MM / 28IN - CONT’D 22...................
SCRUB HEAD GROUP, ORBITAL 700MM / 28IN 24
RECOVERY TANK GROUP 26..................
RECOVER Y TANK FILTER AND HOSE GROUP,
SCREW CAP 28.............................
SOLUTION TANK GROUP 30...................
STANDARD ELECTRICAL GROUP 32...........
FRAME AND DRIVE GROUP 34.................
HEAD LIFT GROUP, DISK 36...................
HEAD LIFT GROUP, CYLINDRICAL 38...........
HEAD LIFT GROUP, ORBITAL 40................
SHROUD GROUP, DISK AND ORBITAL 42.......
SHROUD GROUP, CYLINDRICAL 43............
LOWER CONSOLE GROUP, ON- BOARD
CHARGER 44...............................
LOWER CONSOLE GROUP, OFF- BOARD
CHARGER 46...............................
CONSOLE HANDLE, PRO- MEMBRANE
PANEL 48..................................
CONSOLE HANDLE, PRO- PANEL LCD 50.......
SQUEEGEE LIFT GROUP 52...................
SQUEEGEE ASSEMBLY, 500MM / 20IN 54.......
SQUEEGEE ASSEMBLY, 650MM / 26IN 56.......
SQUEEGEE ASSEMBLY, 700MM / 28IN 58.......
SQUEEGEE ASSEMBLY, 800MM / 32IN 60.......
STANDARD PARTS - Cont’d
STANDARD SOLUTION GROUP 62.............
BATTERY CABLES GROUP 64..................
LABEL GROUP 65.............................
ELECTRICAL DI AGRAM 66.....................
ELECTRICAL HARNESS, MAIN 70..............
ELECTRICAL HARNESS, OPERATOR
STATION 74................................
ELECTRICAL HARNESS, BAIL SWITCH 76.......
OPTIONS
ACCESSORY RAIL CLIP KIT 77.................
TELEMETRY ELECTRICAL GROUP 78..........
ec-H2O SOLUTION GROUP 80.................
SEVERE ENVIRONMENT SOLUTION GROUP 82.
RECOVERY TANK RINSE KIT 84................
PARKING BRAKE GROUP 86...................
SOLUTION TANK AUTO-FILL KIT 88.............
CONTROL VALVE DRAIN HOSE KIT 90..........
BATTERY GROUP, WET 225AH 91..............
BATTERY GROUP, WET 260AH 92..............
BATTERY GROUP, AGM 220AH 93..............
SMART-FILLt AUTOMATIC BATTERY
W ATERING GROUP 94......................
HYDROLINKR MANUAL BATTERY
W ATERING KIT 96...........................
DOCUMENTATION GROUP 98..................
BREAKDOWNS
ec- H2O NANOCLEAN MODULE BREAKDOWN 100
ORBITAL HEAD ECCENTRIC DRIVE
BREAKDOWN 102............................
