STANDARD PARTS
Tennant T500 (01- 2017)
45
LOWER CONSOLE GROUP, ON- BOARD CHARGER
Ref. Part No. Serial Number Description Qty.
1 1203802 (10000000- 20000000 ) Cover, Column, Cntrl 1

2 1011402 (10000000- 20000000 ) Switch, Key 1
Y
3 1017696 (10000000- 20000000 ) Key Set, Replmt [F/ Keyswitch 1011402] 1
4 582150 (10000000- 20000000 ) Plug, Hole, Rt, 1.23 X 1.12, Nyl 2
5 1011735 (10000000- 20000000 ) Switch, Safety, Shutoff 1
6 1064038 (10000000- 20000000 ) Gauge, Hourmeter, 05- 277 Volt, Ac / Dc 1
7 1205496 (10000000- 20000000 ) Hook, Cord 2
8 1043573 (10000000- 20000000 ) Screw, #10- 14 X 0.675, Spl[Shcs,Selftap] 9
9 130773 (10000000- 20000000 ) T ie, Cable, Nyl, 11.0l, .14w , 3.0 Max. D 3
10 1207290 (10000000- 20000000 ) Cover , Charger 1
11 611311 (10000000- 20000000 ) Spring, Cmpr, 0.40od .05wir 00.5l, Pl,Mw 2
12 1024965 (10000000- 20000000 ) Bolt, Shld, 08mmd X 030mm, M06 X 1.0 2

13 1220856 (10000000- 20000000 ) Charger , 24vdc 25a 115- 240vac [On- Board] 1
Y
14 605387 (10000000- 20000000 ) Connector, Anderson, 050a, Red [W/O Con] 1
15 1025642 (10000000- 20000000 ) Cord, Power , 16/3, 15ft Blk [Us] 1
15 1026330 (10000000- 20000000 ) Cord, Power, 1.0mm2 [2.5meter] 1
15 1026325 (10000000- 20000000 ) Cord, Power , 1.0mm2/3 Blk[2.5meter, Aus] 1
15 1048304 (10000000- 20000000 ) Cord, Power [4.5meter, India, S.Africa] 1
16 1020341 (10000000- 20000000 ) Screw, Hex, M8 X 1.25 X 20, Ss, Sems 4
17 1211903 (10000000- 20000000 ) Frame, Column, Cntrl [Im] 1
18 378969 (10000000- 20000000 ) Clamp, Cable, Stl, 0.56d X 0.38w, 1hole 1
 ASSEMBLY
Y INCLUDED IN ASSEMBLY
