25
1
Door handle
for charcoal door (16)
1 Locking plate,
for charcoal door (17)
1 Handle bezel (18)
for charcoal door
1 Trolley handle (19)
1 Side rack, right (20)
with hooks
1 Lid (21) with upper
hinge and ventilation
controller
1 Lid handle (22)
4 Handle bezel for
lid and ash
collecting tray (23)
1 Ash collecting
tray (24)
1 Handle for ash
collecting tray (25)
1 Warming grille (26)
1 Grid in grid
BBQ grate (27)
2 Joint (28)
Fasteners
A Nut M10 1
B Screw (M6x10) 1
C Was
her M6x16 1
D Nut M6 1
E Spring washer 6M 1
F Washer M6x12 1
G Srew M5x28 2
H Hinge pin 2
I Splint pin 3
J Screw M5x18 2
Please check that the delivery is complete
and undamaged. Should a part be missing
or defective, please contact your dealer.
Claims relating to damages or missing
parts made after assembly has taken place
or commenced will not be recognised.
P180146-TEPRO_1164_Grillwagen_Toronto_Click_DE_GB_20180815.indd 25 15/8/2018 11:15 AM
