Terex RL4000D2 Series User Manual

November 2006
P
a
r
t
N
o
.
8
3
3
0
0
5
R
e
v
A
R
L
4
0
0
0
L
i
g
h
t
T
o
w
e
r
1
3
SETUP
F
.
When applicable,
drive grounding rod
into earth. (Grounding
rod not included)
1.
Drive the rod into the
ground and secure the grounding wire
to the lug located on the
trailer frame.
G
.
When applicable, install
the floodlights on the
crossarm.
1.
Remove the light fix
tures from their pack
ing boxes and install them
on the crossarm
with the lens facing upward as shown above.
2.
The cord on the fixture should
be on the side closest to t
he trailer so the cord entry is
beneath the fixture when the tower is raised
(this reduces moisture problems and
insures the water weep hole in the
fixture is down).
3.
Set the vertical aim for
each light fixture by adjusting
the light fixtures and tight
ening
the nuts.
Ne
ver adjust fixt
ures with po
wer on.
4.
Set the spread bet
ween the fixtures
horizontally by adjust
ing the fixtures
and tighten
ing
the
mounting
nut.
5.
The light fixtures m
ay be left on the unit
when towed around the job
site.
6.
Plug each fixture int
o the receptacles
provided. Plug into the
numbered receptacles in
a clockwise rotation starting at the upper or
1:00 o’clock position. This makes trouble
shooting easy without lowering the
tower
.
If T
ungsten Halogen lamps are used, the cord m
ust
be routed
and secured awa
y fro
m th
e fixture. Fa
ilur
e to do s
o may
result in cord bur
n-through a
nd short
circuit due to the high
fixtur
e temperature
.
T
owing
Chain
T
ongue J
ack
Outrigger Pin
Outrigger Jack
FIRM AND LEVEL AREA
Rear Jack
