TermaTech TT20 User Manual

3
INSTALLATION INSTRUCTION
The stove is intended for ”intermittent combustion”. It is not me-
ant to “heat over” at night. By following the instruction below in
“Lighting instruction” the best and most environmentally friendly
combustion is achieved.
The wood-burning stove is delivered ”ready for mounting” (the
exhaust branch may need to be screwed on) and must be connected
to the chimney with a smoke pipe. The connection between stove
and chimney must, as far as possible, be mounted in one straight
piece (with as few bends as possible) and as minimum horizontally,
but preferably rising from the stove to the chimney. Joints must be
tight. Remember that is has to be possible to clean the pipe (possi-
bly with a cleaning hatch on the pipe).
Any unauthorised changes to the wood-burning stove will be viewed
as a structural change and thereby the warranty will be void and is
also a risk to safety.
In the door on your TT stove there is a spring that makes the door
close by itself when you let go of the handle.
This closing device is not a demand in the UK, Denmark and many
other countries and can therefore be removed. In the bottom hinge
the split with lentil head is removed which removes the tension from
the spring. This is most easily done by using a small screw driver
and side-cutting pliers.
National and European norms
The regulations in force at the time in question, including those
that refer to national and European standards, must be respected
when installing the wood-burning stove. Contact your local dealer
for further advice and guidance in connection with mounting. No-
tify your Hetas installer before you use your wood-burning stove. It
must be ensured that there is sufcient airow for the combustion
in the stove, so care must be taken concerning closely shut windows
and doors that may hinder the ow of air to the combustion.
Safety references
The surface of the stove as well as knobs, handle, window, smoke
pipe, etc. become very hot when the stove is in use. Touching these
parts without necessary protection (glove or other protective mate-
rial) can lead to burns.
Remember to make children aware of this danger and make sure to
keep them away from the wood-burning stove when it is in use. For
this purpose TermaTech offers various grates for the protection of
children. (Ask your dealer)
Allowed in the wood-burning stove
Only use dry and clean wood for combustion in the wood-burning
stove. Maximum size of logs used in the stove is up to 30 cm in
length and 10 cm in diameter.
Only use dry wood. The burning of waste, synthetic materials and

TermaTech TT20 Specifications

General

Nominal Output	5 kW
Flue Outlet	150 mm
Fuel type	Wood
Heating capacity	30-120 m2
Log length (max)	33 cm
