Contents Page
1 Main features 5
2 Keyboard 6
3 Starting up 11
3.1 Establishing probe constant for length measurement 14
with inversion of the probing direction
3.2 Programming retraction travel 19
3.3 Capturing a reference value 20
3.4 PRESET function 24
4 Display 25
4.1 Main display 26
4.2 Display format in mode measurement 27
5 Configuration menu 28
5.1 Unit system 28
5.2 Printing a language or header 29
5.3 Temperature stabilisation 29
5.4 Standard parameters 30
5.5 RS 232 input/output 31
5.6 Printer 31
5.7 Temperature compensation 32
5.8 Date and time 36
5.9 Header text 36
5.10 Default parameters 37
6 Features and functions 38
6.1 Measuring lengths using the function « Single probe contact » 38
6.2 Measuring lengths using the function « Dual probe contacts » 38
6.3 Measuring grooves 39
6.4 Measuring ribs 40
6.5 Measuring bores 42
6.6 Measuring shafts 45
6.7 Calculating a median 48
6.8 Calculating a distance 51
6.9 Measuring a diameter or a width 55
