INSERTING THE BOBBIN
1: Orient the bobbin with the thread running to the left.
2: Place the bobbin in the bobbin holder.
3: Guide the thread into the notch on the front of the bobbin holder. The
dotted line on the illustration shows the correct thread direction..
4: Draw the thread to the left, sliding it between the tension spring blades.
5: Continue to draw the thread lightly until the thread slips into the notch on the
side. The bobbin should rotate freely.
6: Pull out about 10 cm (4”) of thread to the rear.
7: Reattach the hook cover plate.
Inserting and threading the bobbin is much easier when the needle is
fully retracted and the presser foot raised. See Page 6 for details.
Page 9
