Tesira EX-MOD - Specifications

6
TESIRA EX-MOD SPECIFICATIONS
Tesira EX-MOD Specications
Frequency Response
(20Hz~20kHz @ +4dBu):
+0/-0.25dB Phantom Power: +48 VDC
(7mA/input)
THD+N (20Hz~20kHz):
@ 0dB Gain, +4dBu In
@ 54dB Gain, -50dBu In
< 0.006%
< 0.040%
Cross Talk (channel to channel @ 1kHz):
@ 0dB Gain, +4dBu In
@ 54dB Gain, -50dBu In
< -85dB
< -75dB
EIN (20Hz~20kHz, 66dB Gain, 150Ω): < -125dBu Input Gain Range (6dB Steps): 0 - 66dB
Dynamic Range (20Hz~20kHz, 0dB): > 108dB Sampling Rate: 48kHz
Input Impedance (balanced): 8kΩ A/D – D/A Converters: 24-bit
Output Impedance (balanced): 200Ω Power Consumption
(100~240VAC 50/60Hz):
< 40W
Maximum Input: +24dBu Weight: 7 lbs (3.2 kg)
Maximum Output: +24dBu Compliance:
FCC Part 15B (USA)
CE Marked (Europe)
C-Tick (Australia)
UL/C-UL Listed
RoHS Directive (Europe)
Overall Dimensions:
Height:
Width:
Depth:
1.75 inches (44 mm)
19.0 inches (483 mm)
10.5 inches (267 mm)
