Performance Front Brake Pad
Thickness (excluding back plate)
New: 0.393"/10 mm Service limit: 0.085"/2.15 mm
Performance Rear Brake Pad
Thickness (excluding back plate)
New: 0.354"/ 9 mm Service limit: 0.071"/1.8 mm
Parking brake Electrically actuated parking brake integrated into rear caliper
Suspension
Suspension Specifications
Front Independent, double wishbone, coil spring/telescopic damper, sway bar
Rear Independent, multi-link, coil spring/telescopic damper
Battery - Low Voltage
Battery -
Low Voltage
Specifications
Rating 33 amp hour or higher
Voltage and Polarity Low voltage
negative (-) ground
Battery - High Voltage
Type Liquid-cooled lithium ion (Li-ion)
Nominal Voltage 360 V DC
Temperature Range Do not expose
Model Y to ambient temperatures above 60° C or below -30° C for more than
24 hours at a time.
Subsystems
191Specifications
