5
ENG
Hinge
grommet
Pliers
Not level
Fastener-ring
Lower hinge
Levelling feet
L
H
The picture above is only for reference. The actual configuration will depend on the physical product or
statement by the distributor.
Levelling door
The picture above is only for reference.
The actual configuration will depend on
the physical product or statement by the
distributor.
1. Raise the lower door up to the level of the higher door.
2. Insert the supplied fastener-ring by using plier in the gap between the hinge-grommet and the lower
hinge.The number of fasten-rings you will need to insert depends on the gap.
List of tools to be provided by the user
plier
