PULLER-TENSIONER
Model: AFB506
Manual: MI-AFB506-149-00-GB
Date: 05.10.2016
Author: B. Ghezzi
Page: 12 of 37
4.4 MACHINE SET-UP
Before the use, the machine must be set in stand-alone using mode, operating on the control panel
(table 1).
a. insert and turn the ignition key (table 1, pos. 17) in "1" position
b. wait up to the multifunction display switch on (table 1, pos. 14)
c. on the electronic multifunction display press the () key
d. on the screen page “MACHINE ID:” set the number “1” by using the up () or down () key
e. press the return key ( ) to save the settings
NOTE: in case of stand-alone
using mode the ID of the machine
must always be set at 1
f. on the screen page “BULL WHEELS PIN CONNECTION?” set the “YES” or “NO” option,
depending on the configuration of use (table 5, pos. 1), by using the up () or down () key
g. press the return key ( ) to save the settings.
When the machine is used in stand-alone
configuration the two plug connectors must be
closed with the related caps
