PULLER-TENSIONER
Model: AFS404
Manual: MI-AFS404-609-01-GB
Date: 15.03.2016
Author: MC
Page: 15 of 35
Selecting "System Information", will appear on the menu bar icon dedicated
in which will be displayed serial number and firmware version installed
6. Diagnostic Menu
Displays the menu and the engine list alarms
Displays active alarms
DM1 from engine ECU (if present)
Displays alarms
DM2 saved by engine ECU
(if present)
Erase memory
DM2 engine ECU alarms
Selecting the center button on the menu bar,
you enter the page describing the error
appeared.
SPN / FMI Alarms
Alarms Description
Alarm list DM1/DM2
(DM2 only from engine)
Unit failed and its address:
0 = engine
128 = AF3-CV
