PULLER
-
TENSIONER
Model: AFS404
TABLE 3.7
1) Manometer with graduated ring nut.
2) Emergency stop push button.
3) Connected machines selector (optional)
4) Bull-wheels control lever.
5) Pull value setting device.
6) Pull value setting knob.
7) Manometer for overfeeding pressure.
8) Fan function selector.
9) Speed synchronizer selector (optional).
10) Adjusting valve for reel elevator/reel winder pressure.
11) Manometer for reel elevator/reel winder pressure.
12) Diesel engine accelerator.
13) -.
14) Diesel engine ignition key.
15) -.
16)
17) Multi-functional display.
18) Generator lamp.
19) Fuel pilot lamp.
20) Pilot lamp for electric pull limiting device exceeding.
21) Pre-heating glow plugs lamp.
22)
23) Fine braking pilot lamp.
24) F1 filter pilot lamp.
25) F2 filter pilot lamp.
26) -.
27) Selector for compressor connection (optional).
28) Alarm lamp card.
29) Lever for front plough movement.
30) Rope locking device selector (optional).
31) Engine cooler temperature.
32) Engine oil lamp.
