Testboy 114 - Technical Details and Maintenance; Device Modifications and Cleaning; Flashlight Functionality; Changing the Batteries

Safety notes
14 Testboy
®
114
All parts of the device and its accessories are not allowed to be changed or replaced , other than
authorized by the manufacturer or his agent.
For cleaning the unit, use a dry cloth.
Flashlight
Turn on the built-in flashlight with the switch (1b). Using a high-performance LED a burning time
of up to 60 hours per set of batteries is possible! The life of the LED is over 100,000 hours.
Changing the batteries
Insert a screwdriver in to the notch (2) and pry the battery compartment cover off. Make sure you
insert the batteries the right way round!
Do not dispose of batteries in normal household rubbish! Use an authorised local
collection point!
Technical data
Voltage range
12 - 1000 V AC
Power supply
2 x 1.5 V AAA Micro
Degree of protection
IP 40
Overvoltage category
CAT III 1000 V
Testing standard
IEC/EN 61010-1
(DIN VDE 0411)
