Shenzhen TestPad Electronic Co., Ltd. http://www.test-pad.com
21
The tester accumulates the charged capacity during the charge process and accumulates the
discharged capacity during the discharge process. When the discharge ends, the displayed
recharged capacity indicates the capacity of the battery working in the current mode.
Caution: By default, both charge current and discharge current of the battery are 1C of the battery
capacity set. If a low discharge current is needed, set a low battery capacity; if a high charge
current is needed, set a high battery capacity. In 1C mode, a complete capacity test may take 3~4
hours. If a relatively low battery capacity is set, the test will take a bit longer time.
During the test, you can press ENTER anytime to pause the test. After that, press ENTER again to
continue the test, or press ESC to abort the test and return to the setting mode.
Lion: It indicates that the current battery type is Li-ion battery. For other battery types, it
may be NiMH, NiCd, or SLA.
CV: Constant voltage
CC: Constant current
TC: Trickle current, small current (0.1C by default)
OC: Over charge
OD: Over discharge
CHARGE: Charge status
DISCHR: Discharge status
WAIT..34: Waiting status; and 34 seconds are left.
Lion CV CHARGE RUN
RUN TIME: 00:03:17
V = 8.42V I=0.468A
CHARGE CAP: 26mAH
