TESY ModEco Series - Page 75

Type D, [mm] H, [mm] L, [mm] F, [mm]
B, mm E, mm K, mm
GCV6S 8047../GCV6SL 8047..
470
850
295 243 496 202 120
GCV9S 10047../GCV9SL 10047..
470
990
445 243 496 202 120
GCV9S 12047../GCV9SL 12047..
470
1155
445 243 496 202 120
GCV9S 15047../GCV9SL 15047.. 470
1320
445 243 496 202 120
GCV11SO 15047../GCV11SLO 15047..
470
1320
565 243 496 202 130
1
GCVSL
GCVS
K
E
H
G
B
D
G
G
G
L
F
max 310 mm
min 220 mm
max
max
min
min
GCVS[L]
100 mm
C
min 300 mm
min 100 mm
min 700 mm
min 100 mm
min 100 mm
❹
1ⓓ
