12 (61) Version 4.3
Connectors in the front panel
GPS Antenna Connector (§4.6 )
External Smart Card Connector (§4.5 )
Connectors in CUR-3
Speaker microphone connector (§4.1)
Helmet cable connector (§5 )
Overall diameter: 5.9±0.2 mm
Minimum bending radius: 5 x D
See Chapters 7.1.1 and 7.1.2 for placements of speaker microphone
and helmet cable connectors.
All optional accessories which will be connected to CUR-3 control unit
shall be EMC tested before use.
