Connectors and PIN-layouts
Version 4.3 11 (61)
4 Connectors and PIN-layouts
Connectors in the back-front
1. System Connector (§4.2 )
.2 Control Unit Interface Connector (§4.3 )
Installation cables from 0.75m to 10m
Overall diameter: 8.3±0.2 mm
Minimum bending radius: 5 x D
3. Auxiliary Accessory Connector (I/O Pins) (§4.4 )
Antenna Connector (§0)
Warning: Both Control unit and auxillary connectors are DB-26
female. Make sure you connect the CUR-3 cable to connector 2,
otherwise I/O can be damage and radio should go to repair center.
