TEV marstair MRC+ Series - Page 2

2/27
55008351-23
CONTENTS
PAGE
DIMENSIONS & WEIGHTS (packed & unpacked) & SPECIFICATION.
3
PERFORMANCE DATA.
4-11
MOUNTING, DIMENSIONS & WEIGHTS.
12-13
PIPEWORK.
13-14
ELECTRICAL & FUSES.
14-16
REFRIGERANT.
17-18
END OF LIFE REQUIRMENTS.
19
ECO DESIGN INFORMATION TABLES.
20-27
COMPONENT IDENTIFICATION MRC+.
28-29
1. TEV LTD recommend that personnel working on this equipment be skilled and fully conversant
with the appropriate Refrigeration and Electrical practices and have sound knowledge of current
Industrial Safe Working practices.
2. These units are supplied with a holding charge of oxygen free nitrogen and polyolester oil.
Do not mix oils or refrigerants.
3. These units when installed contain live electrical components, moving parts and refrigerant under
pressure. Always site out of reach of children and protect from vandalism.
4. The data plate only gives information for the outdoor unit. For system details add input power and
current of indoor and outdoor unit, including any heater load.
5. FUSES - for recommended fuse size see page 12.
6. The refrigerant used should be identified by locating a refrigerant label on the unit case
INDEX
GENERAL
NOTE
IF MECHANICAL PUMP DOWN OPERATION IS REQUIRED CONNECT A LINK WIRE
BETWEEN TERMINALS L1 & 3.
IF THIS LINK IS USED THEN TERMINAL 5 CAN NOT BE USED AS AN ALARM FACILITY
