UNPACKED
MRC+ CONDENSING UNITS
MODEL
15
20
30
40
45
50
60
80
90
100
130
150
165
180
HEIGHT
mm
620
620
620
620
720
720
720
720
820
820
1080
1080
1080
1275
WIDTH
mm
900
900
900
900
1000
1000
1000
1000
1000
1000
1000
1000
1000
1100
DEPTH
mm
300
300
300
300
350
350
350
350
350
350
425
425
425
425
1 Ph kg
46
47
48
53
61
64
65
66
76
81
-
103
-
-
3 Ph kg
-
-
48
53
-
64
65
66
76
81
101
103
103
118
PACKED
MRC+ CONDENSING UNITS
MODEL
15
20
30
40
45
50
60
80
90
100
130
150
165
180
HEIGHT
mm
620
620
620
620
720
720
720
720
820
820
1080
1080
1080
1280
WIDTH
mm
980
980
980
980
1090
1090
1090
1090
1090
1090
1090
1090
1090
1215
DEPTH
mm
340
340
340
340
390
390
390
390
390
390
465
465
465
465
1 Ph kg
48
49
50
(43*)
55
(47*)
63
66
67
68
78
85
-
107
-
-
3 Ph kg
-
-
50
55
-
66
67
68
78
85
105
107
107
123
MRC+
15
20
30
40
45
50
60
80
90
100
130
150
165
180
Nominal cooling
capacity (-10°C
evaporating
temp & 32°C
ambient temp)
R404A
kW
1Ph
3Ph
1.1
-
1.4
-
2.0
2.0
2.9
2.9
2.9
2.9
3.9
3.9
4.6
4.6
5.5
5.5
6.4
6.4
7.1
7.1
-
8.1
8.8
8.8
-
10.5
-
11.6
Operating weight
kg
1Ph
46
47
48
53
61
64
65
66
76
81
-
103
-
-
3Ph
-
-
48
53
-
64
65
66
76
81
101
103
103
118
1 Ph (230V 50Hz) compressor load only (at nominal cooling capacity)
Power (nominal)
kW
0.82
1.12
1.42
2.07
1.43
2.03
2.26
2.61
3.03
3.92
-
4.52
-
-
Starting current
LRA
A
23
28
36
50
35
58
61
76
110
114
-
142
-
-
Nominal current
FLA
A
5.9
6.9
8.1
10.2
10.0
8.9
9.8
11.5
16.9
20.5
-
32.3
-
-
3Ph (400v 50Hz) compressor load only (at nominal cooling capacity)
Power (nominal)
kW
-
-
1.42
2.07
-
2.03
2.26
2.61
3.03
3.92
4.46
4.52
5.29
5.82
Starting current
LRA
A
-
-
18
22
-
26
32
40
48
51
62
68
71
71
Nominal current
FLA
A
-
-
3.6
4.8
-
4.2
4.2
4.9
7.1
7.2
7.7
8.7
9.5
11.9
Sound Pressure Levels (SPL) at 10m distance in free field conditions @ 27°C external ambient.
Fan speed max
dBA
34
34
34
34
33
33
33
34
37
38
37
37
37
39
NR
28
28
28
28
27
27
27
27
30
31
30
30
30
32
Condenser fan (1Ph 230V 50Hz)
Airflow (max
speed)
m³/s
0.40
0.40
0.97
0.97
0.97
0.97
0.97
0.97
0.97
0.97
1.85
1.85
1.85
1.85
Fan motor rating
kW
0.65
0.65
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
2x0.13
2x0.13
2x0.13
2x0.13
Nominal current
FLA
A
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
2x0.6
2x0.6
2x0.6
2x0.6
Fans: No. x
diameter
#x
mm
1x350
1x350
1x457
1x457
1x457
1x457
1x457
1x457
1x457
1x457
2x457
2x457
2x457
2x457
Fans max speed
r.p.m
940
940
940
940
940
940
940
940
940
940
940
940
940
940
DIMENSIONS AND WEIGHTS
SPECIFICATION DETAILS
