5-V Power
AWR1642
Flash
60-pin HD
Connector
Micro USB
Connector
SOP ControlsNRST_SWGPIO1_SW
Onboard Antenna
CAN-FD
Connector
www.ti.com
Hardware
3
SWRU508B–May 2017–Revised April 2018
Submit Documentation Feedback
Copyright © 2017–2018, Texas Instruments Incorporated
AWR1642 Evaluation Module (AWR1642BOOST) Single-Chip mmWave
Sensing Solution
2 Hardware
Figure 1 and Figure 2 show the front and rear view of the EVM, respectively.
Figure 1. EVM (Front)
