11 List of Materials
The List of Materials is Based on Figure 1 and Figure 2.
Table 4. UCD3138PFCEVM-026 List of Materials
QTY REF DES DESCRIPTION PART NUMBER MFR
1 C1 Capacitor, tantalum, 25 V, 20%, 10 µF, 3528 TPSB106M025R180 AVX
0
0 C10, C11 Capacitor, ceramic, 50 V, X7R, 10%, open, 1206 Std Std
2 C12, C20 Capacitor, ceramic, 50 V, X7R, 10%, 1 nF, 0805 Std Std
1 C16 Capacitor, ceramic, 50 V, X7R, 10%, 0.01 µF, 0805 Std Std
0 C17, C25, C29 Capacitor, ceramic, 50 V, X7R, 10%, open, 0805 Std Std
2 C2, C3 Capacitor, metalized polyester, 250 VAC, ±20%, 47 nF, 0.472 ECQ-U2A473MV Panasonic
inch x 0.925 inch
1 C21 Capacitor, tantalum, 10 V, 20%, 10 µF, 3216 TAJA106M010RNJ AVX
1 C22 Capacitor, film, 300 VAC, ±20%, 47 nF, 0.236 inch x 0.591 inch ECQ-U3A473MG Panasonic
1 C26 Capacitor, ceramic, 50 V, X7R, 10%, 1 µF, 0805 Std Std
1 C30 Capacitor, ceramic, 50 V, X7R, 10%, 330 pF, 0805 Std Std
1 C31 Capacitor, tantalum chip, 16 V, 47 µF, 0.281 inch x 0.126 inch 595D476X9016C2T Vishay
1 C32 Capacitor, ceramic, 50 V, NP0, 5%, 150 pF, 0805 Std Std
4 C33, C39, C40, Capacitor, polyester, 630 V, 10%, 47 nF, 0.256 inch x 0.650 inch ECQ-E6473KF Panasonic
C41
1 C34 Capacitor, aluminum electrolytic, 450 VDC, -40°C to 85°C, ±20%, ECOS2WP221CX Panasonic
220 µF, 0.984 inch diameter
2 C35, C36 Capacitor, ceramic, 50 V, X7R, 10%, 100 pF, 0603 Std Std
2 C37, C38 Capacitor, film, 275 VAC, ±20%, 0.47 µF, 0.236 inch x 0.591 inch ECQU2A474ML Panasonic
7 C4, C18, C19, Capacitor, ceramic, 50 V, X7R, 10%, 0.1 µF, 0805 Std Std
C23, C24, C27,
C28
3 C5, C6, C7 Capacitor, metalized polyester, 250 VAC, ±20%, 4.7 nF, 0.295 BFC233820472 Vishay
inch x 0.730 inch
5 C8, C9, C13, Capacitor, ceramic, 50 V, X7R, 10%, 0.1 µF, 0603 Std TDK
C14, C15
9 D1, D2, D3, Diode, dual Schottky, 200 mA, 30 V, SOT23 BAT54S Zetex
D4, D6, D15,
D22, D23, D25
2 D11, D12, D24 Diode, Schottky, 500 mA, 30 V, SOD123 MBR0530T1G On Semi
2 D13, D14 Diode, Schottky rectifier, 10 A, 600 V, TO-263-2 C3D10060G CREE
1 D16 Diode, 600 V, 6 A, 400 A peak surge, P600 6A6-T Diodes
1 D17 Diode, bridge rectifier, 8 A, 600 V, 0.880 inch x 0.140 inch GBU8J Fairchild
1 D18 Diode, LED, green, 2.1 V, 20 mA, 6 mcd, 0603 LTST-C190GKT Lite On
1 D19 Diode, LED, green, 2.1 V, 20 mA, 0.9 mcd, 0.068 inch x 0.049 LN1371GTR Panasonic
inch
1 D20 Diode, LED, red, 2.1 V, 20 mA, 6 mcd, 0603 LTST-C190CKT Lite On
1 D21 Diode, LED, yellow, 2.1 V, 20 mA, 6 mcd, 0603 LTST-C190YKT Lite On
1 D5 Diode, signal, 300 mA, 75 V, 350 mW, SOD-123 1N4148W-TP MICROSEMI
1 D7 Diode, ultrafast rectifier, 1 A, 200 V, SMB MURS160T3G On Semi
1 D8 Diode, dual Schottky, 200 mA, 30 V, SOT-23 BAT54C Fairchild
2 D9, D10 Diode, Schottky, 500 mA, 60 V, SOT-23 ZHCS506 Zetex
1 DB-1 Module, 5 W, auxiliary bias PS, PCB assembly, 1.200 inch x PWR050 TI
2.200 inch
1 DB-2 Control card, UCD3138 control card, PCB assembly, 3.400 inch x UCD3138CCEVM- TI
1.800 inch 030
