CESSNA SECTION 1
MODEL 172R GENERAL
Weight in Baggage Compartment, Normal Category:
Baggage Area 1 (Station 82 to 108): 120 lbs. See note below.
Baggage Area 2 (Station 108 to 142): 50 lbs. See note below.
NOTE
The maximum combined weight capacity for Baggage Area 1
and Baggage Area 2 is 120 lbs.
Weight in Baggage Compartment, Utility Category:
In this category, the rear seat must not be occupied and the
baggage compartment must be empty.
STANDARD AIRPLANE WEIGHTS
Standard Empty Weight: 1639 lbs.
Maximum Useful Load, Normal Category: 818 lbs.
Maximum Useful Load, Utility Category : 468 lbs.
CABIN AND ENTRY DIMENSIONS
Detailed dimensions of the cabin interior and entry door openings
are illustrated in Section 6.
BAGGAGE SPACE AND ENTRY DIMENSIONS
Dimensions of the baggage area and baggage door opening are
illustrated in detail in Section 6.
SPECIFIC LOADINGS
Wing Loading: 14.1 lbs./sq. ft.
Power Loading: 15.3 lbs./hp.
Revision 7 1-7
