Page L-3
699361 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
SEATING
10 01006G01 Hex Washer Head Thread Forming Screw, 3/8" - 16 x 1.25" Lg ..................... 2
11
12
13
14
15
16 *** Seat Bottom Assembly (Includes Items 17 - 26).............................................. 1
629269G0101 Oyster
629269G0103 Tan
629269G0104 Gray
629269G0106 Black
629269G0107 Brown
629269G0109 White/Blue
629269G0110 Red/Black
629269G0111 White/Red
629269G0112 White/Black
629269G0113 White/Yellow
629269G0114 Gray/Black
629269G0115 Oyster/Garnet
17 00720G08 Flat Head Phillips Tapping Screw, #12 - 14 x 1" Lg................................... 6
18 17074G1 Soiling Slab ............................................................................................... 2
19 615417 Button Head Torx Bolt, M10 - 1.5 x 25mm Lg ........................................... 4
20 617644 Hip Restraint (Passenger Side)................................................................. 1
21 617645 Hip Restraint (Driver Side) ........................................................................ 1
22 645492 Base.......................................................................................................... 1
23 71012G01 Trim (Polypropylene) ................................................................................. 1
24 *** Vinyl Cover................................................................................................ 1
71602G02 Gray
71602G03 Oyster
71602G04 Tan
71602G06 Black
71602G07 Brown
604912G0102 White/Blue
604912G0103 White/Red
604912G0104 White/Black
604912G0108 White/Yellow
604912G0304 Red/Black
604912G0506 Oyster/Garnet
604912G0704 Gray/Black
25 71603G02 Padding (Foam) ........................................................................................ 1
To Next Page
